Legacy versions of the Ioline Control Center Interface for adjusting plotter parameters are available below. These versions are not updated or officially supported. For assistance finding the Control Center software compatible with your equipment, please contact Ioline Customer Service

Control Center Release 12.4 (English)

Interface for adjusting plotter parameters for old versions of the 600Ae, 600AeX, 28Ae, Stylist Ae, Studio A, 200, 300, 350HF, 100, and SmarTrac I/S.
Download:ioline_cc_setup_r12.4.exe
Revision: 12.4
OS: Windows® (x32 and x64): XP, Vista, Win7
Posted:July 7, 2010
Size: 3.4 MB
Install: Copy the file to the PC connected to the plotter and run it by double-clicking on it. Follow the on screen directions to complete the installation. The equipment User Guide has directions for using the Control Center.

Control Center Release 9 (English + Español)

Interface for adjusting plotter parameters for the 600A, 28A, Studio 40, Summit 910/2200, Appli-K System, Classic, Classic+ & Super 88.
Download:ioline_ccl_setup.exe
Revision: 9
OS: Windows® 2000, XP, Vista (32-bit Editions)
Posted: May 6, 2005
Size: 2.6 MB
Install: Copy the file to the PC connected to the plotter and run it by double-clicking on it. Follow the on screen directions to complete the installation. The equipment User Guide has directions for using the Control Center.

Control Center Release 9 (Chinese)

Chinese Interface for adjusting plotter parameters for the 600Ae, 600AeX, 28Ae, Stylist Ae, Studio A, 200 System, 300 System, 350HF System, 100 System, SmarTrac I/S, and SmarTrac Contour.
Download:ioline_cc_setup_ch.exe
Revision: 3
OS: Windows® 2000, XP, Vista (32-bit Editions)
Posted: June 4, 2004
Size: 2.4 MB
ReadMe: You must have Chinese fonts available for the program to properly display. Install the Chinese version of older versions Windows®, enable support Chinese characters in new versions of Windows®, or have a program like RichWin (http://www.richwin.com/) installed before running setup.

Web resources for Chinese font sets:

Install: Copy the file to the PC connected to the plotter and run it by double-clicking on it. Follow the on screen directions to complete the installation. The equipment User Guide has directions for using the Control Center.

Control Center (16 bit) Release 4.6.0 (English) English version

Interface for adjusting plotter parameters for the 28, 28M, 28P, 600, 600M, 600P, Appli-K System, Super88, Classic, Studio 8, Summit 2200/910, and StudioA.
Download:wscc_460.exe
Revision: 4.6.0
OS: Microsoft Windows® 3x, 9x
Posted: May 10, 1999
Size: 703 KB
Install: Copy the file to the PC connected to the plotter and run it by double-clicking on it. Follow the on screen directions to complete the installation. The equipment User Guide has directions for using the Control Center.

Control Center (16 bit) Release 2.4 (English) English version

Interface for adjusting plotter parameters for the Studio 7 and Summit.
Download:wscc_24.exe
Revision: 2.4
OS: DOS®
Posted: May 10, 1999
Size: 1 MB
Install: Copy the file to the PC connected to the plotter and run it by double-clicking on it. Follow the on screen directions to complete the installation. The equipment User Guide has directions for using the Control Center.

Control Center Release 5 – MacIntosh® Platform version

MAC interface for adjusting plotter parameters for the 600Ae, 600AeX, 28Ae, Stylist Ae, Studio A, 200 System, 300 System, 350HF System, 100 System, SmarTrac I/S, and SmarTrac Contour.
Download:Ioline_Installer.hqx
Revision: 5
OS: MAC System 7.5.3 or later
Posted: October 4th, 2000
Size: .98 MB
Install: Copy the file to the MAC connected to the plotter and run it by double-clicking on it. Follow the on screen directions to complete the installation. The equipment User Guide has directions for using the Control Center.
ReadMe: Ioline Control Center Version 5 for the Macintosh® requires:

– System 7.5.3 or later
– A PowerPC or newer processor
– The Communications ToolBox and the Serial Tool Extension

Serial Tool Extension: This installer will add the Serial Tool Extension to the Extensions Folder in the active System Folder if it does not already exist. It will not replace the Serial Tool Extension if it is already there.

To connect an Ioline plotter to your computer you will need an available serial port or a USB to serial adapter.

USB Users: If you have a newer Macintosh® that does not have a serial port, but instead has USB ports, you will need to purchase a USB to Serial adapter to connect an Ioline plotter to your computer. We have tested our software successfully with the Keyspan USB to Serial Adapter and we recommend you use that device for reliable connectivity.

Control Center Release 4.4 – MacIntosh® Platform version

MAC interface for adjusting plotter parameters for the Summit 910/2200, Super 88, Classic and Studio 8.
Download:mcc_44.sit.hqx
Revision: 5
OS: MAC System 7.0 or later
Posted: May 10, 1999
Size: 428 kb
Install: Copy the file to the MAC connected to the plotter and run it by double-clicking on it. Follow the on screen directions to complete the installation. The equipment User Guide has directions for using the Control Center.
ReadMe: Binhexed Macintosh Version

AutoCAD Drivers

AutoCAD® 10 & 11 driver

Legacy drivers for AutoCAD® 10 & 11
Download: acad1011.exe
Posted: 2001.02.01
Size: 49 KB
Description: A README.DOC is included for simple installation instructions. There are also other drivers within these versions of AutoCAD® that the plotters will emulate. In the plotter configuration menu, you may select several Houston Instruments® drivers that can work with an Ioline plotter like the DMP-52, DMP-56, DMP-62.
To install: Self-extracting file. Copy the file to the PC and install.

AutoCAD® 12 driver for DOS® and Windows®

Legacy drivers for AutoCAD® 12
Download: pliol.exe
Posted: 2001.02.01
Size: 88 KB
Description: There are two drivers in this file, pliol.dll is the Windows driver, and pliol.exp is the DOS driver. A README.DOC is included for simple installation instructions. There are also other drivers within these versions of AutoCAD that the plotter will emulate. In the plotter configuration menu, you may select several Houston Instruments® drivers that can work with an Ioline plotter like the DMP-52, DMP-56, DMP-62.
To install: Self-extracting file. Copy the file to the PC and install.

AutoCAD® 13 & 14 driver

Legacy drivers for AutoCAD® 13 & 14
Download: acad13.exe
Posted: 2001.02.01
Size: 59 KB
Description: This driver is written for the DOS version of AutoCAD® 13. However, our plotters will emulate other plotters whose drivers are in the Windows® versions of AutoCAD® 13 and 14. In the plotter configuration menu, you may select Houston Instruments® or HP® plotters, many of which will work as drivers for the Ioline plotters. If your Ioline plotter was manufactured prior to October of 1987, it may not recognize the HP/GL language, in which case it would be best to select one of the Houston Instruments® plotters. There are several Houston Instruments® drivers that you can emulate to use with an Ioline plotter. For example: DMP-52, DMP-56, DMP-62
To install: Self-extracting file. Copy the file to the PC and install.

Generic Windows Drivers

Ioline does not write generic Windows drivers. Most sign-making software includes the necessary drivers to connect an Ioline plotter to your computer. If your design software does not come with its own drivers, there are other ways to send the design to the plotter.

For example many of the sign-making software companies, such as Scanvec-Amiable®, and others, have products that can import files from popular graphic applications such as CorelDRAW!®, FreeHand®, Adobe Illustrator®, and other graphics programs. These products are generally much less expensive than a full sign making software package. Contact the software manufacturers for further information.

Third party HP/GL drivers called Winline Plus and CoCut is used with various Windows® programs and Ioline equipment. For information on these drivers, please contact:

Winline Plus HP/GL Drivers
Software Mechanics® Pty Ltd.
38 Railway Tce Brisbane
Brisbane QLD 4064
Australia
Sales: 61-7-3371-9499
Fax: 61-7-3870-4732
info@winline.com
www.winline.com

CoCut HP/GL Drivers
Euro-Systems S.à r.l.
Villa Machera
1 Rue Kummert
L-6743 Grevenmacher
Luxembourg
Tel: ++352-267-456-03
Fax: ++352-267-456-05
sales@eurosystems.lu
www.cocut.com
